29
TROUBLESHOOTING — CONTINUED
Will not bend Rigid or
IMC conduit.
Clevis pin is inserted in the shoe hole
for EMT conduit.
Move clevis pin to the shoe hole
marked for Rigid/IMC conduit (See
Figure 10A on page 10).
Follow bar is in backwards. Remove follow bar and install with
the end marked “START” just past the
roller assembly (see Figure 10C on
page 10).
Hydraulic cylinder will
not advance.
Hydraulic pump is low on oil. Refer to operating instructions for the
hydraulic pump and add oil.
Hydraulic fittings are not fully
tightened.
Check all hydraulic fittings and tighten.
Too long of an extension cord causing
voltage drop to the hydraulic pump.
Pump not properly vented.
Hydraulic cylinder pinned too
high in the frame for the size
conduit being bent.
Pump valve lever in wrong position.
Pump not operating properly.
Use heavier gauge extension cord
and/or shorter extension cord.
Remove the plug used during shipping
and replace with the correct vent plug.
Reposition hydraulic cylinder to the
proper position in the frame.
Rotate pump valve lever to the closed
position.
Check pump manual for trouble
shooting.
Hydraulic cylinder
advancing slowly
Pump valve not fully closed Ensure pump valve lever is in the fully
closed position
ALWAYS disconnect the bender from the hydraulic pump
before servicing and when not in use.
WARNING
