Current Tools 254 - Major Components - Shoe Groups; Conduit Centerline Bending Radii

7
4"
2 1/2"
254-110 – For bending 2 1/2" EMT, IMC and Rigid conduit
Key Catalog# Description
1 254-111 Bending Shoe – 2 1/2"
2 254-112 Follow Bar – 2 1/2"
3 254-114 Saddle – 2 1/2"
3 1/2"
254-124 – For bending 3 1/2" EMT, IMC and Rigid conduit
Key Catalog# Description
1 254-125 Bending Shoe – 3 1/2"
2 254-126 Follow Bar – 3 1/2"
3 254-128 Saddle – 3 1/2"
CONDUIT CENTERLINE BENDING RADII
MAJOR COMPONENTS – SHOE GROUPS
3"
Size 2 1/2" 3" 3 1/2" 4"
EMT
13
1
⁄2" 16
1
⁄8" 18
5
⁄8"
21"
IMC
13
1
⁄2" 16
1
⁄8" 18
5
⁄8"
21"
RIGID
13
1
⁄2" 16
1
⁄8" 18
5
⁄8"
21"
254-117 — For bending 3" EMT, IMC and Rigid conduit
Key Catalog# Description
1 254-118 Bending Shoe – 3"
2 254-119 Follow Bar – 3"
3 254-121 Saddle – 3"
254-131 – For bending 4" EMT, IMC and Rigid conduit
Key Catalog Description
1 254-132 Bending Shoe – 4"
2 254-133 Follow Bar – 4"
3 254-135 Saddle – 4"
3
2
1
2
3
1
1
2
3
2
3
1
