Current Tools 254 - Values for Layout of Common Bends

20

Chart D – 2 1/2" EMT

D = 6 1/8 HEIGHT

ANGLE DIM 10 12 16 20 24 30 36 42 48 60

15°

M 25 1/8 32 13/16 48 5/16 63 3/4 79 3/16 102 3/8 125 9/16 148 3/4 171 15/16 218 5/16

C 38 5/8 46 5/16 61 13/16 77 1/4 92 11/16 115 7/8 139 1/16 162 1/4 185 7/16 231 13/16

K 42 1/4 50 65 7/16 80 7/8 96 3/8 119 1/2 142 11/16 165 7/8 189 1/16 235 7/16

E 47 1/8 54 5/8 69 1/2 84 7/16 99 3/8 121 3/4 144 3/16 166 9/16 188 15/16 233 3/4

30°

M 7 1/4 11 1/4 19 1/4 27 1/4 35 1/4 47 1/4 59 1/4 71 1/4 83 1/4 107 1/4

C 19 13/16 23 13/16 31 13/16 39 13/16 47 13/16 59 13/16 71 13/16 83 13/16 95 13/16 119 13/16

K 27 1/8 31 1/8 39 1/8 47 1/8 55 1/8 67 1/8 79 1/8 91 1/8 103 1/8 127 1/8

E 30 15/16 34 3/8 41 5/16 48 1/4 55 3/16 65 9/16 75 15/16 86 3/8 96 3/4 117 1/2

45°

M 3 8 11/16 14 3/8 20 28 1/2 37 45 7/16 53 15/16 70 15/16

C 22 27 11/16 33 5/16 41 13/16 50 5/16 58 13/16 67 5/16 84 1/4

K 32 15/16 38 5/8 44 1/4 52 3/4 61 1/4 69 11/16 78 3/16 95 3/16

E 33 11/16 37 11/16 41 11/16 47 11/16 53 11/16 59 11/16 65 11/16 77 11/16

60°

M 2 5/8 7 1/4 11 7/8 18 13/16 25 3/4 32 11/16 39 9/16 53 7/16

C 21 5/8 26 3/16 33 1/8 40 1/16 47 53 15/16 67 13/16

K 36 1/8 40 3/4 47 11/16 54 5/8 61 9/16 68 1/2 82 3/8

E 33 3/4 36 1/16 39 1/2 43 46 7/16 49 15/16 56 13/16

90°

M 2 1/2 8 1/2 14 1/2 20 1/2 26 1/2 38 1/2

C 30 1/16 36 1/16 42 1/16 54 1/16

K 51 7/8 57 7/8 63 7/8 75 7/8

E 33 15/16 33 15/16 33 15/16 33 15/16

VALUES FOR LAYOUT OF COMMON BENDS

Chart E – 2 1/2" RIGID/IMC
