Wireless Adapter (WA100-PM)
Test Suite 8:
Dimming Driver + Photosensor
1.
Press and immediately release the blue Reset button. The red Error LED flashes once, then pauses and repeats.
2. Check that the lights connected to the driver cycle from maximum to minimum brightness then turn Off,
then repeat.
3. Press and immediately release the blue Reset button again. The red Error LED flashes three times, then pauses
and repeats.
4. The light connected to the driver turns On.
5. Increase the amount of light at the photosensor by shining a bright light at it. The light’s output is proportional
to the amount of light received by the photosensor.
•
For dimming
lights, shine a bright light at the photosensor – the light gets brighter.
Cover the photosensor – the light gets dim.
• For switched lights, cover the photosensor – the light turns Off.
Shine a bright light at the photosensor – the light turns On.
6. Press and immediately release the Reset button to exit testing.
7. Press and hold the blue RESET button on the WA100-PM for 3 seconds to reset the unit. Release the button
when the green Joined LED and the red Error LEDs begin flashing.
Test Suite 9:
Occupancy Sensor + Photosensor
1.
Press and immediately release the blue Reset button. The red Error LED flashes twice, then pauses and repeats.
2. Trigger the occupancy sensor. The green Joined LED turns On. When the sensor times out the Joined LED
turns Off.
3. Press and immediately release the blue Reset button again. The red Error LED flashes three times, then pauses
and repeats.
4. The green Joined LED begins to flash. Increase the amount of light at the photosensor by shining a bright light
at it. The green Joined LED flashes at a faster rate.
5. Press and immediately release the Reset button to exit testing.
6. Press and hold the blue RESET button on the WA100-PM for 3 seconds to reset the unit. Release the button
when the green Joined LED and the red Error LEDs begin flashing.
