INSTALLATION WALKTHROUGH:
For more information log onto www.curtmfg.com, & for helpful towing tips log onto www.hitchinfo.com
3. Fishwire a 7/16" carriage bolt and CM-SP2 spacer
through the access hole and out each of the two
forward holes in the bottom of the passenger side
frame rail as shown.
4. Remove the contents of the trunk including the spare tire.
5. Remove the middle plug on the driver side of the spare
tire well. Return plug to vehicle owner.
6. Raise hitch into position over the exhaust, threading the
passenger side fishwire through the slot in the passenger
side mounting plate. Secure the passenger side with the
(2) 7/16" hex flange nuts as shown. Take care not to push
the carriage bolts into the frame rail.
To Next Page
