APPENDIX C
C-2
Table C-2 Electrical Specifications, 1209/1221
NOMINAL INPUT VOLTAGE 24–36V, 36–48V, 48–72V, 48–80V, and 72–120V
PWM OPERATING FREQUENCY 15 kHz
CONTROL INPUT LEVEL
KSI/forward/reverse from 8 V to 1.5 × maximum battery voltage
Emergency reverse from undervoltage cutback level to 1.5 × max. battery voltage
STANDBY CURRENT less than 100 mA
STANDARD THROTTLE INPUT 0–5kΩ ±10% (others available)
NOMINAL VOLTAGE UNDER- MAX TOTAL
BATTERY CURRENT 2 MIN 5 MIN 1 HOUR DROP VOLTAGE F/R + 1A
MODEL VOLTAGE LIMIT RATING RATING RATING @ 100 AMPS CUTBACK CURRENT
NUMBER (volts) (amps) (amps) (amps) (amps) (volts) (volts) (amps)
1209 -46XX 24–36 500 500 350 225 0.15 16 2
-55XX 36–48 450 450 300 200 0.30 21 1
-64XX 48–72 400 400 275 175 0.30 32 1
-6A5XX 48–80 450 450 300 200 0.25 32 1
-72XX 72–120 275 275 175 100 0.70 48 1
1221 -48XX 24–36 600 600 425 250 0.10 16 2
-57XX 36–48 550 550 375 225 0.25 21 1
-66XX 48–72 500 500 350 200 0.25 32 1
-6A7XX 48–80 550 550 375 225 0.20 32 1
-74XX 72–120 400 400 250 150 0.50 48 1
