Curtis PMC 1204X/1205X/1209/1221 Manual
49
APPENDIX C
C-1
TABLE C-1 Electrical Specifications, 1204X/1205X
NOMINAL INPUT VOLTAGE 12V, 24–36V, and 36–48V
PWM OPERATING FREQUENCY 15 kHz
CONTROL INPUT LEVEL
KSI/forward/reverse from 8 V to 1.5 × maximum battery voltage
Emergency reverse from undervoltage cutback level to 1.5 × max. battery voltage
STANDBY CURRENT less than 250 mA
STANDARD THROTTLE INPUT 0–5kΩ ±10% (others available)
NOMINAL VOLTAGE UNDER- MAX TOTAL
BATTERY CURRENT 2 MIN 5 MIN 1 HOUR DROP VOLTAGE F/R + 1A
MODEL VOLTAGE LIMIT RATING RATING RATING @ 100 AMPS CUTBACK CURRENT
NUMBER (volts) (amps) (amps) (amps) (amps) (volts) (volts) (amps)
1204X-12XX 12 275 275 200 125 0.35 9 2
-14XX 12 400* 300 210 135 0.25 9 2
-42XX 24–36 275 275 200 125 0.35 16 2
-44XX 24–36 400* 300 210 135 0.25 16 2
-52XX 36–48 275 275 200 125 0.35 21 1
1205X-14XX 12 400 400 275 175 0.25 9 2
-16XX 12 500* 425 285 185 0.20 9 2
-44XX 24–36 400 400 275 175 0.25 16 2
-46XX 24–36 500* 425 285 185 0.20 16 2
-53XX 36–48 350 350 250 150 0.35 21 1
* 30-second rating
APPENDIX C
ELECTRICAL SPECIFICATIONS
