3. PRINTER FUNCTIONS
3-12
DPT100-B/I/BT
17$B1$
[Name] Disables underlined printing
[Format] ASCII ESC q
Hex 1B 71
Decimal 27 113
[Description] Annuls underlined printing
[Notes]
[Default]
[Reference] $1B $51
[Example]
37$B1$
[Name] Transmits the next character in serial
[Format] ASCII ESC s
Hex 1B 73
Decimal 27 115
[Description] Transmits the next character it receives on the serial port
[Notes]
[Default]
[Reference]
[Example] If you transmit: $1B $73 $41
the last character, $41, will not be printed but immediately transmitted on the serial line
2n1nAF$B1$
[Name] Print graphic bank ( 384
× ×
× ×
× 85 dots).
[Format] ASCII ESC { } n1 n2
Hex 1B FA n1 n2
Decimal 27 250 n1 n2
[Range] 0 ≤ n1, n2 ≤ 255
[Description] Prints the graphics bank from flash.
n1 specifies the starting dot line ( 1 ÷ 85 ).
n2 specifies the number of lines to print.
[Notes] • If n1 + n2 > 85 the printer only prints 85 - n1 + 1 dotlines.
[Default]
[Reference]
[Example] To print the graphic bank from dotline 10 to dotline 40, send:
$1B $FA $0A $1E
67$B1$
[Name] Transmit paper sensor status
[Format] ASCII ESC v
Hex 1B 76
Decimal 27 118
[Description] When this command is received, transmit the current status of the paper sensor.
[Notes] • This command is executed immediately, even when the data buffer is full (Busy ).
The status to be transmitted is shown in the table below:
