§ Cd02
Select Main monitor display (Selective range 0~10）
The monitor is consisted of four 7-segment LEDs, displays frequency, current and
various data by digital number and character.
Cd02=0 Display the frequency, LED HZ active
Cd02=1 Display the current, LED A active
Cd02=2 Display Ultimate speed, Hz and A LED de-active.
Cd02=3 Display DC voltage of DC BUS, showing d in front of value
Cd02=4 Display rms value of U.V.W. AC output，LED HZ, A active
Cd02=5 Display external control terminal status, showing E in front of value
Cd02=6 Display temperature rising of PIM module, showing b in front of value
Cd02=7 Display speed feedback. Check if MCK circuit working properly, then the
restart and free run start function (Cd28) will working normally.
Cd02=8 Display current step of multi-step function (step)
Cd02=9 Display current time of multi-step function (minutes)
Cd02=10 Display motor vibration
§ Cd03
Torque mode (Selective range 0~1)
The function cannot be modified during revolution
.
Cd03=0 Automatic torque compensation de-active, set compensation by Cd07
Cd03=1 Initial Torque boost active，set compensation by Cd52
Set compensation by Cd63
§ Cd04
Operation command mode
(Selective range
0~5
）
The function cannot be modified during revolution
Cd04=0 Operation on operation panel 1, press ▲▼key to display the content of
Cd02
Cd04=1 2 wire Operation by external terminal 1, including FR, RR, terminal (1, 2, 3,
4), press ▲▼key to display the content of Cd02
Cd04=2 Operation on operation panel 2, ▲▼key fine tuning frequency
Cd04=3 2 wire operation on external terminal 2，including FR, RR, terminal (1, 2, 3,
4), ▲▼key fine tuning frequency
Cd04=4 3 wire Operation by external terminal 1, including FR, RR, terminal (1, 2, 3,
4), press ▲▼key to display the content of Cd02
Cd04=5 3 wire operation on external terminal 2，including FR, RR, terminal (1, 2, 3,
4), ▲▼key fine tuning frequency
