Die mounting direction
Return to Bend
Numerical Page
Bottoming
Basic die data
Die more specic data
Browsing through
existing dies
Die name
Touch the die to display
its default shape, allowing
an easier identication of
the various dimensions
CybTouch 12 PS User Manual
dieS
Bend Numerical Page →
Setting inStructionS:
Selecting a die is the same as selecting a punch; simply browse through the existing dies
in your library using the arrows buttons, and then return to Bend Numerical Page.
