Table 5.1: LED Load Light Indication
LED : Green (G), Orang (O), Red (R)
LED Note
(G)
(G)
(G)
Min. load - 50% ± 5%
(G)
(G)
(O)
50%±5% - 80% ± 5%
(G)
(G)
(R)
80% ± 5% - Max. load
Note: Flash per second. Light on. Light off.
LED : Red
LED Note
Output overload 100~115% : error code
Output overload 115~150% : error code
Output overload 150~200% : error code
Note: Flash per second. Light off.
6.Installation & Wiring:
(A) Wiring for Batteries: Wire connections should be as short as possible and less than 1.5
meter is highly recommended. Make sure that correct wires are chosen based on the rating
current. Wires with lower specication may result in overheat or re that induces certain
danger. Please refer to Table 6.1 and consult our local distributors to ensure safety.
