2.1 Features
• True sine wave output (THD<3%)
• High efciency up to 93%
• Rated output
• Surge power
• Complete LED indication for operating status
• Battery low alarm and indicator
• Selectable output voltage / frequency
• Fully digital control
• Can be used for most of the electronic products with AC input
• 3 years global warranty(2 years global warranty for Fan)
• Fast transfer time (<10ms)
• Compliance with ANSI/UL60950, CAN/CSA-C22.2, EN60950, FCC Part15, EN55022
2.2 Main Specication
MODEL
CPS3000SA12 CPS3000SA24 CPS3000SA48 CPS3000ESA12 CPS3000ESA24 CPS3000ESA48
OUTPUT
RATED POWER 3000W
MAX. POWER 3450W 200 sec. / 4500W 10 sec.
SURGE POWER 6000W > 0.5 s
FREQUENCY 120V ±3% and 50Hz / 60Hz ±0.001Hz 230V ±3% and 50Hz / 60Hz ±0.001Hz
WAVEFORM True sine wave (THD <3.0%)
PROTECTION AC Short, Overload, Over Temperature
DC INPUT (Battery)
BAT. VOLTAGE 10.5 ~15.0V 21.0 ~30.0V 42.0 ~ 60.0V 10.5 ~15.0V 21.0 ~30.0V 42.0 ~ 60.0V
DC CURRENT
(Max)
320A 155A 77A 320A 155A 77A
EFFICIENCY 89% 91% 92% 89% 91% 92%
OFF MODE CURRENT Under 1.0mA at power switch off
PROTECTION Over Load, Battery Polarity, Reverse by Fuse, Battery Low Shutdown, Battery Low Alarm
OTHER
DIMENSION(L*W*H) 470.4*310*96mm
WEIGHT 12.4Kg
COOLING Temperature controlled fan
MODEL
CPS1500SA12 CPS1500SA24 CPS1500SA48 CPS1500ESA12 CPS1500ESA24 CPS1500ESA48
OUTPUT
RATED POWER 1500W
MAX. POWER 1725W 200 sec. / 2250W 10 sec
SURGE POWER 3000W > 0.5 s
FREQUENCY 120V ±3% and 50Hz / 60Hz ±0.001Hz 230V ±3% and 50Hz / 60Hz ±0.001Hz
WAVEFORM True sine wave (THD <3.0%)
PROTECTION AC Short, Overload, Over Temperature
DC INPUT (Battery)
BAT. VOLTAGE 10.5 ~15.0V 21.0 ~30.0V 42.0 ~ 60.0V 10.5 ~15.0V 21.0 ~30.0V 42.0 ~ 60.0V
DC CURRENT
(Max)
166A 81A 40A 166A 81A 40A
EFFICIENCY 90% 91% 91% 90% 92% 93%
OFF MODE CURRENT Under 1.0mA at power switch off
PROTECTION Over Load, Battery Polarity, Reverse by Fuse, Battery Low Shutdown, Battery Low Alarm
OTHER
DIMENSION(L*W*H) 287.4×310×96mm
WEIGHT 6.63kg
COOLING Temperature controlled fan
