HARDWARE INSTALLATION CONT.
The MBP can be mounted in a rackmount or vertical tower orientation. Please follow the instructions
below for the respective mounting methods.
1. Brackets installation
Attach the two brackets to the MBP using the provided screws M4X6L*4pcs.
1
1
1
1
2
2
2
MBP mounted horizontally in a rackmount
MBP mounted vertically in a rackmount
