MBP FRONT PANEL DESCRIPTION
HARDWARE INSTALLATION
1. UPS INPUT SWITCH
2. Input/Output terminal blocks connect to UPS
3. “Bypass” Red light LED indicator (Bypass source ready)
4. “Normal” Green light LED indicator ( UPS source ready OK to switch )
5. MAINTENANCE BYPASS SWITCH
6. 20A circuit breaker for L6-20 outlet
7. L6-20 outlet
8. L6-30 outlet
9. 30A circuit breaker for L6-30 outlet
10. Input terminal blocks connect to utility and Output terminal blocks connect to equipment load
11. MBP detection port
9 111 3 4 6 7
2 5 8 10
To Next Page
