46
4. Adjust the Recline Foot so that the
Recline Angle remains in the blue zone
on the Recline Indicator as shown on
page 67.
5. While pushing down on the SafeLock
Belt Tensioner A, squeeze the gray
button B toward the rear of the seat,
then lift the Belt Tensioner to open.
Installing and Removing the Infant Car Seat
Installing with Base Using Lap/Shoulder Belts
Recline Indicator
CY_172_0695_A1123
1.8 - 13.6 kg
(4 - 30 lb)
r
t
A
B
To Next Page
