Cybex Arc Trainer 630A Owner’s Manual
NOTE: The AC power kit is optional on the 630A Arc Trainer.
Make sure that the unit is connected to an outlet having the same configuration as the plug. NOTE: Do
not use a ground plug adapter to adapt the 3-prong power cord plug to a non-grounded electrical
outlet.
NOTE: Use Cybex supplied AC power kit only. Consult an electrician if you have any questions.
Setup
and Assembly
Page 5-2
Electrical Power Requirements
! WARNING: Use extreme caution when assembling the unit. Failure to do so could result in
injury.
! CAUTION: A minimum of two people are required to assemble this unit.
Tools Required
• Phillips head screwdriver
• Torque wrench
• 3/16” Allen wrench (supplied)
• 7/32” Allen wrench (supplied) (2)
• 9/16” Open-end wrench
NOTE: The words “left” and “right” denote the user’s orientation.
1. Read and understand all instructions thoroughly before assembling the unit.
NOTE: Each step number in the assembly instructions tells you what you will be doing. The lettered
steps following each step number describe the procedure required. Do not continue with step 2
until you have carefully read all of the assembly instructions.
2. Verify you have received the correct package.
A. Read the sticker on the outside of the box and verify that the model number and voltage are
what you ordered.
3. Unpack and verify the contents of the boxes.
A. Lift up and remove the cardboard sleeve that surrounds the unit.
B. Verify that you have the color that you ordered by looking at the paint.
C. If you ordered the optional AC power kit, verify that you have the correct power cord by
reading the voltage sticker near the power inlet.
Assembling the 630A Arc Trainer
