Cybex Arc Trainer 630A Owner’s Manual
Setup
and Assembly
Page 5-3
D. Check to be sure that the following items are present. Check off ( ) each item as you find it.
See Figure 1. If any of the parts are missing contact Cybex Customer Service.
Item Qty Part Number Description
1 1 Varies Base with covers attached
2 1 Varies Console assembly (in box)
3 1 PL-17209 Water bottle holder (in box)
4 2 11090-405 Foot pad (in box)
5 1 AW-19522 Power cord 115 VAC (optional)
5 1 AW-19521 Power cord 230 VAC (optional)
5 1 AW-19587 Power cord 100 VAC (optional)
5 1 EW600005 Power cord 220 VAC (optional)
6 Not used
7 1 NA Hardware pack (in box)
8 1 5630A-4 Owner’s Manual (in box)
9 1 630A-352 Assembly poster
10 1 600A-301 Warranty sheet
NA 1 610A-373 Instruction, 630A Assembly Note
NA means Not Applicable
Figure 1
#7 #8 #9 #10
#5
(Optional)
#2
#3
#4
#1
To Next Page
