Page 6-12
C1 1 630A-200 Frame, Front
C2 1 630A-201 Bracket, Transformer
C3 2 630A-305 Spacer, Insulating
C4 1 630A-314 Clamp, Battery
C5 1 630A-316 Controller Cover
C6 1 600A-313 Shaft
C7 1 630A-328 Belt, Secondary Drive, 7 Rib
C8 1 600A-337 Pully, Poly-V Die Cast, 16 Grooves
C9 2 600A-340 Bearing, 1.00 Inch Pillow Block
C10 1 600A-343 Belt, Primary Drive 16 Rib
C11 2 01250 Double Sided Foam Tape, 0.75
C12 1 AD-18442 PCA, Control Board
C13 1 AF-19518 Plate, Power Inlet, Blank
C14 1 AX-19550 Assembly, Brake Generator
C15 2 BR030221 Ring Retaining, Exterior Cresent
C16 1 DE-17155-* Warning Decal
C17 1 DE-19586 Decal, Warning Icon, Battery
C18 1 DE-19593-* Decal, Lower Control Cover
C19 1 EC-18267 Battery, 12 VDC
C20 2 FB030243 Bearing, 25 MM ID X 52 MM OD 6205
C21 1 FM-16859 Shaft, Lower
C22 2 FM-19507 Counterweight, Pulley
C23 2 HC661240 Screw, Hex Head Cap .312-18 x 3.75
C24 4 HC661217 HX HD Cap Screw .312-18 x 1.00
C25 4 HC701254 HX HD Cap Screw .375-16 x 5.50
C26 2 HF540201 Nut, Grommet, Spacer
ITEM QTY PART NO. DESCRIPTION
C27 4 HF579000 Nut, U type 10-24 Panel
C28 4 HN704901 Locknut, .375-16 Nylon
C29 2 HS307600 Washer, SAE .250
C30 2 HS308300 Lockwasher Split .250
C31 4 HS347600 Washer, Sae .375
C32 8 HS347700 Washer, USS .375
C33 4 HS760100 Spring Retaining Washer
C34 11 HT572512 Screw, Tap No. 10 - 24 X .50 Pan Head
C35 2 HX-17023 Pin, Spring .1875 x .75 LG Type 420
C36 2 HX-17050 Bushing, 1.275 ID x 1.87 OD, Nylon
C37 4 630A-327 Sleeve, Generator Isolation
C38 1 HX-19504 Spacer, Generator Isolation
C39 2 JC700922 Screw, FHSCS .375-16 X 1.50
C40 4 JC702820 Screw, Soc Hd Cap .375 X 16 X 1-1/4
C41 1 PW-16521 Pulley, Drive
C42 1 TR-18448 Transformer, 24v DC IEC-320 Input
C43 1 630A-315 Plate
C44 1 AW-18447 Battery Cable (Not Shown)
C45 1 CM000243 Label, Calibration
ITEM QTY PART NO. DESCRIPTION
Front End Assembly
Cybex Arc Trainer 630A Owner’s Manual
