Electrical Power Requirements
The AC power kit is optional.
Use Cybex supplied AC power kit only. Consult an electrician with any questions.
Verify the unit is connected to an outlet having the same configuration as the plug.
Verify connection is a grounded circuit. Do not use a ground-plug adapter to adapt the 3-prong power
cord to a non-grounded electrical outlet.
Verify power supply is compliant with local building codes.
Assembly Procedure 626A/627A
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Tools Required
• Phillips screwdriver
• Stubby Phillips screwdriver
• 7/32” Allen wrench (included)
• 9/16” Open end wrench (2)
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base with covers attachedVaries11
Console assemblyVaries12
Foot pad12090-32223
Handle, RightNA14
Handle, LeftNA15
Base, Accessory tray770A-31616
Cover, Top, Accessory tray770A-31717
Cover, Bottom, Accessory tray770A-31818
Page 13 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
