CYBEX Arc Trainer 626A - Handrail Installation

2. Install the accessory tray bottom to the accessory tray base with three screws using a Phillips
screwdriver.
QtyDescription
1Accessory tray bottom1
1Accessory tray base2
3Screws3
Install handrails
1. Remove three locknuts from the left support leg using two 9/16" open end wrenches. Keep the two
spacers in place.
QtyDescription
3Locknuts1
2Spacers2
1Left handle3
2. Install the left handle and three locknuts using two 9/16" open end wrenches.
Page 20 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
