CYBEX Arc Trainer 626A - Page 37

Install rear covers
1. Install the left inner rear cover with two screws using a Phillips screwdriver.
Qty.Description
1Left inner rear cover1
2Screws2
2. Install the left outer rear cover with five screws using a Phillips screwdriver.
Qty.Description
1Left outer rear cover1
2Screws2
3. Install the left top rear cover with five screws using a Phillips screwdriver.
Qty.Description
1Left top rear cover1
5Screws2
4. Repeat steps for the right side.
Page 37 of 83
Cybex 626A/626AT, 627A/627AT Arc Trainer Part Number 5626-4 J
