Cybex 445T Treadmill Owner’s Manual
Appendix C
Page C-2
ITEM QTY. PART NO. DESCRIPTION
NO.
70 9 HS-11977 Screw, SEMS, 8/32 x .38, PNHD
74 2 CW-22240 Wheel, 80mm Dia. x 32mm
75 4 HB-18768 Bearing, LF-1011-12
76 2 HS-60022 Bolt, 3/8 x 2.25, HXHD CAP, Black Zinc, G5
77 2 HN-60064 Nut, Jam 3/8 - 16, Black Zinc
78 1 AF-18481 Weldment, Motor Base
79 2 HX-22247 Bushing, Spanner, .500 OD x 1.5”L
80 2 HB-18768 Bearing, LF-1011-12
81 1 AD-19085-Q PCA, Control Board, 115 VAC, 445T
81 1 AD-19086-Q PCA, Control Board, 230 VAC, 445T
82 1 SW-19666 Switch, Rocker, Thermal CB, 15 A
82 1 SW-19667 Switch, Rocker, Thermal CB, 20 A
83 1 EC-18896 Filter, 16 Amp
83 1 EC-19869 Filter, 20 Amp
84 4 HN-11136 KEPS, 5/16 - 18, HEX STL ZINC
86 8 EH-00986 Wire Tie, Nylon, 9
87 2 HN-11925 KEPS, 10-32, HEX STL ZN
88 1 HW-10856 Washer, Lock External, No. 10 ZC
90 1 EH-12260 Wire Tie, Nylon, 18
91 1 FS-19668 Plate, Circuit Breaker Mount
92 1 DE-20427 Label, Disconnect Power, Multilingual
93 1 DE-19238 Decal, Warning, Motor Plate
94 1 DE-19198 Decal, Cybex
95 1 AF-18728 Bracket, Idler
96 1 HB-19135 Idler Wheel, 1.88 x 1.0
97 2 HB-18056 Bushing, Flange, .375 x .469 x .25
98 1 HS-19338 Screw, 3/8 - 16 x 1.75, SCHD BTN, BLK, ZN
99 1 DE-19730-X* Decal, IR Comp Adjust
100 1 HX-17711 Plug, Plastec, 7/16”, Black
101 1 AF-19068 Bracket, Power Factor, Choke
102 1 MR-18402 Motor, Elevation, 115 VAC
102 1 MR-18403 Motor, Elevation, 230 VAC
103 1 AX-19649 Motor, Drive, 110 VAC
103 1 AX-19560 Motor, Drive, 220 VAC
104 1 DE-20685 Decal, E-STOP, Yellow
121 1 EC-15004 Ferrite, Clamp-on, .40 I.D.
122 1 TR-19201 Choke
123 2 HX-19857 Strip, Motor Base, Isolation
124 1 EH-19717 Bushing, Strain Relief, .370”
125 2 HS-18358 Bolt, 5-16-18 x 1.25”, SCHD CAP, BLK ZN
126 2 HW-20044 Washer, Belleville, 15 x 8.2 x 1.0mm, .5mm THK
127 2 HN-20041 Nut, 1/4-20 Propeller .305’ OD
200 1 SCK-18765 Assembly, Top Platform, Right
201 1 SCK-18764 Assembly, Top Platform, Left
202 1 SCK-18486 Weldment, Upright
203 1 AF-20559 Weldment, Frame, 445T
204 2 DE-18766 Decal, Safety Walk
204 2 DE-20718 Decal, Safety Walk, IFI
206 1 PL-18931 Cover, Rear, Top Left
207 1 PL-19120 Cover, Rear, Bottom Left
208 1 PL-18928 Cover, Rear, Top Right
209 1 PL-19118 Cover, Rear, Bottom Right
210 1 DE-19726 Decal, “CX | 445T”, Black
210 1 DE-19727 Decal, “CX | 445T”, Silver 877
211 1 HX-18287 Plug, Hole, Plastic, 1”, Black
220 1 FM-19513 Shaft, Deck Pivot, 445T
221 2 AX-20035 Assembly, Deck Pivot Bracket
222 1 HB-18768 Bearing, IGUS LF-1011-12
223 2 DE-22327 Label, Black, Intelligent Suspension 3
224 2 DE-22328 Label, Silver, Intelligent Suspension 3
225 2 PL-22129 Bracket,Power cord storage, Plastic
226 2 HS-22137 Bolt, 1/4-14 x 1.25”,HXHD Washer,TYP AB,STL ZN
300 1 KAC-20641-X* Assembly, 445T Console
301 1 AX-19356-X* Assembly, Cover, Top CHR
304 1 AD-21468-Q PCA, Display, 445T
305 1 AF-19187 Bracket, Console Anchor, Right
306 1 AF-19188 Bracket, Console Anchor, Left
