Cybex 445T Treadmill Owner’s Manual
Appendix C
Page C-3
ITEM QTY. PART NO. DESCRIPTION
NO.
308 1 DE-18556-X* Decal, Warning, Right
309 1 DE-18557-X* Decal, Warning, Left
310 1 EC-19236 Sensor, Polar Wireless Remote Mount
312 7 HS-41187 Screw, SLFTP, 8-16 x .3125, Plastite
313 1 HX-17788 Tape, Double Sided, .032 Thick
314 2 PL-17686 Tab, Book Holder
315 1 PL-18548 Console, Plastic, 445T
316 1 SW-21456-X* Membrane, 445T, Top
316 1 SW-20701-X* Membrane, 445T, Top, IFI
317 1 SW-21457-X* Membrane, 445T, Bottom
317 1 SW-20700-X* Membrane, 445T, Bottom, IFI
317 1 SW-21458-4 Membrane, 445T, Bottom, With A/V, English only
318 1 DE-19189-X* Label, Warning
410 1 CK-19960 Extended Handrail, Left
411 1 CK-19961 Extended Handrail, Right
413 4 HS-18127 Bolt, 1/4 - 20 x 1.25”
414 1 CK-19962 Extended Handrail, Left and Right, 445T
500 1 AF-19876 Bracket,Upper mount
501 1 AF-21142 Weldment,PEM Mount,2nd Gen
502 1 AW-17694 Cable,Audio 1/”4 in to 3.5mm,18 in
503 1 AW-21680 Cable,Locking RF & DC Power Cable,2795mm
504 1 AW-20111 Cable,5E Bonded pair RJ45 Round
505 1 CN-17687 Adapter, 1/4 Plug to 1/8 Jack
506 1 CP-21072 Monitor,13.3” ATSC NTSC PEM
506 1 CP-21073 Monitor,13.3” DVB-T SECAM PAL PEM
507 1 FS-17698 Clamp, Headphone Adapter
510 2 HS-19369 Screw, 1/4 - 20 x 1.25, PNHD PHIL, Black Zinc
512 1 HX-12244 Spring Compression Brush
513 1 HX-19976 Bushing, Stud Plate, 8-32, 6lb. MAX SHEAR,18lb. Max Comp.
514 1 HX-20032 Insert, Domed Plastic
515 1 HX-20220 Plug, Hole, .187” Dia, Black
523 1 TR-21265 Power Supply,12VDC,120-240VAC,6.0A W-LOCKING PL
524 1 AW-14007 Power Cord, 115VAC, 60hz Power Supply IEC320 (SJT)
524 1 WR-14012 Power Cord, 230VAC, 10A, CEE 7-7, 2M
524 1 AM-20192 Power Cord,100VAC, 50hz, 2.5M IEC-320, Japan
524 1 AW-20193 Power Cord,250VAC 10A,2.5M IEC-320,UK
524 1 AW-22229 Power Cord, 10A, 250VAC IEC 60320 Molded Danish
NS 1 AF-19068 Bracket, Power Factor
NS 1 AW-19117 Cable, A/V Option
NS 1 AW-19679 Cable, Harness, Console
NS 1 AW-18256 Cable, Polar Jumper
NS 1 AW-19678 Cable, Harness, Frame
NS 1 AW-18530 Cable, Filter to Board, Hot, Black
NS 1 AW-18531 Cable, Filter to Board, Neutral, White
NS 1 AW-19714 Power Cord, 115 VAC, 60 Hz
NS 1 AW-19715 Power Cord, 220 VAC, 60 Hz
NS 1 AW-19716 Power Cord, 230 VAC, 50 Hz
NS 1 AW-19878 Power Cord, 230 VAC, 13A, 50 Hz
NS 1 AW-22234 Power Cord, 230 VAC, 10A, 50 Hz
NS 1 AW-18540 Cable, Circuit Breaker to Filter, Hot, Black
NS 1 AW-18541 Cable, Circuit Breaker to Filter, Neutral, White
NS 1 AW-18574 Cable, Speed Signal
NS 1 AW-18973 Cable, Elevation Motor
NS 1 AW-19221-Q Cable, Contact Heart Rate Grip and Ground
NS 1 AW-19235 Cable, Control Board, Ground
NS 1 AX-19193 Controller Mount
NS 1 AX-19354 Kit, Install Hardware
NS 1 DE-18413 Decal, ETL
NS 1 EF-19632 Kit,Fuse Replacement 250 VAC, 15A, Slow Blow
NS 4 EH-10291 Wire Tie, Base
NS 1 EH-19220 Jacket, Corrugated Tubing, 27 Long
NS 1 FS-19190 Controller Mount
NS 1 FS-18771 Cover, Lower, Motor Controller
NS 4 HS-19108 Screw, 5/16-18 x 3/4, LG HXHD, Whiz Lock, GR5
NS 1 HX-19059 Plug, Tube End, 1.5 O.D.
NS 1 KEF-21820 Kit,Fuse Replacement 115 VAC, 20A, Quick Blow
NS 1 LT-03051 Sign Facility Safety
NS 1 LT-19801 Warranty Sheet, 445T
NS 1 LT-19340 Poster, Installation
