Cybex TROTTER Elite Treadmill Owner’s & Service Manual
Display Cable
Tools Required
• Phillips head screwdriver
• ESD (Electro Static Discharge) grounding strap
• Wire cutters
! WARNING: Disconnect the power cord before beginning this procedure. Keep wet
items away from inside parts of the treadmill. Electrical shock could occur
even if the treadmill is unplugged. Do not touch components on the lower
board. A charge can remain after unplugging the power cord and turning
off the treadmill.
1. Disconnect the external power source.
A. Turn the main power switch on the left side to the off (O) position.
B. Unplug the treadmill from the power outlet.
NOTE: The display board is susceptible to damage from a discharge of static electricity.
While handling parts underneath the console cover use an ESD grounding strap. This
eliminates the potential voltage (static) difference between you and the equipment you
are working on. Wear an ESD strap for the rest of this procedure.
2. Remove the top console back.
A. Using a Phillips head screwdriver, remove the five screws that hold the top console
back to the console front.
B. Gently pull off the top console back.
3. Remove the motor cover.
A. Using a Phillips head screwdriver, loosen three screws on each motor cover side (left
and right). See Figure 2.
B. Lift the motor cover center up and off the treadmill. The screws will stay in place.
4. Remove the left junction covers.
A. Using a Phillips head screwdriver, remove the three screws that hold the left junction
covers in place.
5. Remove the display cable.
! WARNING: Do not touch components on the lower board. A charge can remain after
unplugging the power cord and turning off the treadmill.
A. Pull up on the lower board shield until the shield snaps out.
Service
Page 7-34
