CYBEX TROTTER User Manual

5. Attach the console back.
A. While being sure not to pinch any cables, secure the console back to the console with
the five Phillips head screws.
6. Test the new display overlay.
A. Turn the main power switch to the on (I) position.
B. Plug the treadmill into the power outlet.
C. Try each key to be sure that it functions properly.
Parts List
ITEM PART NO. DESCRIPTION
NO.
1 AF-16240 Frame, Weldment
2 HS-16929 Screw, 3-8-16 x 5-8Lg H x HD whiz-lock GR5
3 HS-16950 Screw, 5-16-18 x 7-8Lg H x Soc BtnHD w/patch, B-Zn
4 HS-16939 Screw, SEM 10-32 x .75 Pnhd Ext blk Zn
5 PL-16256 Cover, Motor
6 PL-16465 Cover, Upright Outer, Right
7 PL-16464 Cover, Upright Outer, Left
8 HW-13799 Washer, Flat
9 AX-16721 Deck Stiffener Assy
10 HX-16706 Tape Strip, 1.88 x 41.0 x .010thk
11 HX-16707 Tape Strip, 1.32 x 4.30 x .010thk
12 HS-15682 Screw, 5/16-18 x .50 FLHD Phil undercut ZN
13 AX-16871 Side Extrusion Assy, Elite, Right
14 AX-16725 Side Extrusion Assy, Elite, Left
15 AF-16325 Upright Weldment, (Choose a Standard or or Custom Color)
16 AX-16722 Top Platform Assy, (Choose a Standard or or Custom Color)
17 DE-16705 Decal, Safety-walk
18 HS-16875 Screw, SEM ext 1-4-20 x 1-2 PNHD Phil
19 EH-10291 Anchor, Cable Tie
20 EH-00986 Cable Tie, (without anchor)
21 PL-16737 Plug, Power Cord Grommet
21 AW-17273 Power Cord 220V 60Hz (NOT SHOWN)
21 AW-17272 Power Cord 230V 50Hz (NOT SHOWN)
21 AW-17274 Power Cord 115V 60Hz (NOT SHOWN)
22 PL-16738 Grommet,.45 ID, Power Cord
23 DE-16992 Decal, ETL UL-1647 Only
24 Removed
25 PC-16496 End Cap, Left, (Choose a Standard or or Custom Color)
26 PC-16497 End Cap, Right, (Choose a Standard or or Custom Color)
27 HX-15678 Bushing Deck 5/16-18 40 lbs max shear 185 max comp
28 EH-16809 Grommet, 1.12 x .091-.125 nylon
29 HX-14416 Clip, Cable Retainer
30 DE-16928 Label, Disconnect Power, Multi-languages
31 HW-00590 Bushing Nylon 1-2” Nf810-5-0
32 HX-13771 Ring Retain 5-8” .579 Fr.Id
33 HX-16510 Foot, Rubber, Rear
34 FS-16511 Plate, Rear Rubber Foot Mount
35 HS-16509 Screw ,#10 x .5LG,T-S PLT, PNHD,TYB-B
36 HS-15480 Bolt Tap 1/2-13unc x 6 H x HD GR5
37 HB-16367 Bushing .50ID x .62OD x .31LG,flanged
38 HW-10028 Washer B 1-2 Narrow Zinc
39 HX-11049 Spring 1” O.D.360 Max Ld.
40 AX-16723 Rear Roller Hardware Assembly
40 AF-17591 Nut Holder Bracket
Cybex TROTTER Elite Treadmill Owner’s & Service Manual
Service
Page 7-38
