Cybex TROTTER Elite Treadmill Owner’s & Service Manual
ITEM PART NO. DESCRIPTION
NO.
41 AF-16382 Elevation, weldment
42 HS-60022 Bolt Hhcs 0.375 x 2.25 blk zn G5
43 CW-16712 Wheel, Rubber, 3”Dia
44 HN-60064 Nut, Jam 3-8In.-16 blk zn
46 HS-60021 Bolt Hhcs 0.375 x 2 blk zn G5
47 HS-60023 Bolt Hhcs 0.375 x 2.5 blk zn G5
48 MR-16412 Motor, Elevation 115VAC
48 MR-16541 Motor, Elevation 230VAC
49 SK-17079 Motor, Elevation Tube Nut
50 FT-16825 Sleeve, Elevation Mounting, Top
51 FT-16826 Sleeve, Elevation Mounting, Bottom
52 EC-15783 Filter Line 20 Amp Spade
52 EC-16948 Filter, Power line 20Amp 20EQ1
53 HS-15732 Screw, SEM 8-32 unc x .62 PNHD phil pl
54 HW-10856 Washer (for ground)
55 HN-11925 Nut, Keps 10-32 Hex Stl Zinc
56 PL-17052-4 Cover, Lower Controller, Eng
57 HX-16943 Clip, Christmas Tree, Single Head
58 AX-16835 Lower Control Assy,115V
58 AX-16836 Lower Control Assy,230V
58 AX-17172 Lower Control Assy, 230V 50Hz
59 DE-16608-4 Brush Replacement Gauge, English
60 DE-16610-4 Label, Error Codes, English
61 DE-16609-4 Label, Service Schedule English
62 DE-16708 Decal, Stableflex Logo
63 DE-16373-4 Label, User Precautions
64 DE-16372-4 Label, HR Zone Icons, English
65 AX-16838-4 Accessory Tray Assy, HR Zone, English
66 EH-16977 Fan, Drive Motor, Leeson
67 AW-17704 Motor Ground Wire
68 HW-40004 Washer, Wavy
69 AX-17762 Motor Base Plate Assy
70 HS-16849 Screw, 5-16-18 x 2.0LG H x HD,GR5,Tap
71 HW-00165 Washer, Lock Ex 5-16 Zinc
72 FM-16774 Spacer, Motor Base
73 HB-16426 Bushing Flanged,1.0ID x 1.12OD x .75LG
74 HX-16425 Ring Retaining Ext Crescent
75 FT-16352 Shaft, Motor Mount
76 AW-16830 Cable, Opto Sensor, Armored
77 HW-10772 Washer, Flat No. 4
78 HW-10761 Washer, Lock Ex No.6 Zinc
79 HS-00156 Screw, 4-40 x 0.62 Pnhd Phil
80 AF-17792 Clamp, Motor Drive (includes nut)
81 SK-17248 Kit, Motor, 2.5Hp 220v PMDC 3500RPM Black, Elite and Sport
81 SK-17249 Kit, Motor, 2.5Hp 110v PMDC 3500RPM Black, Elite and Sport
82 DE-16542 Disc, Speed Sensor
83 FM-16463 Flywheel, Drive Pulley Machined
84 HX-11593 Key, Ansi Square 3-16 x 1 3-16
85 HW-16966 Washer, Flat .280 x 1.0 x .125 Steel, Zinc
86 HW-00180 Washer, Lock Split 1/4
87 HS-15757 Bolt, Tap 1/4-28 x 1.0 H x HD PLTD
88 PC-16379 Cover, Junction Outer, Right, (Choose a Standard or or Custom Color)
89 PC-16380 Cover, Junction Inner, Right, (Choose a Standard or or Custom Color)
90 PC-16328 Cover, Junction Inner, Left, (Choose a Standard or or Custom Color)
91 PC-16327 Cover, Junction Outer, Left, (Choose a Standard or or Custom Color)
92 DK-16932 Deck, Plywood 23.3 x 51.5 x 1.0 (Double Sided)
93 BD-16227 Belt, Running, 20.63 x 58 (Light Commercial)
94 HW-00431 Washer, Uss 1-4 x .75 x .062 Zinc
95 HS-16628 Screw, .25-20 x 1.5 Hxhd Grade 8
96 AL-16245-1 Roller, Front Assy
97 AL-16235-1 Roller, Rear Assy
98 BD-16829 Drive, Belt, 8 Rib
99 PL-16408 Console, Back, Plastic
Service
Page 7-39
