~13~
3.5.4.
Deletes all subscriber codes. Enter the number of the subscriber whose keys you want to delete and
confirm with an asterisk.
3.5.5.
Deletes all subscriber's keys (registered) from the control panel memory. It is not possible to undo this operation.
3.5.6.
Deletes all shared subscriber's keys (non-recorded) from the control panel memory. It is not possible to undo this
operation.
4. SYSTEM CONNECTION
The CC4000 system in the basic version for one staircase consists of the CC-4000 control electronics and the
PC-4000 digital panel.
SUPPLY OF POWER CC-4000 control electronics and PC-4000 panel are supplied with 12-13.8V DC. In order to
follow proper working conditions of the system, voltage drops on the power cables must not exceed 1.5V. The
CC-4000 board can power only one SLAVE panel, the panel is powered by + 12V SLAVE connection. If the panel is
located more than 10m away from the control electronics, do not power it from the CC-4000 board, but from a
separate DC power supply. In addition to PC-4000 panel supply of power, we always use a power cable with a
minimum cross-section of 1mm
A
2. Otherwise, there is a risk of incorrect system operation.
UNIPHONES to the CC-4000 board to the L- and L + terminals. It is important that the total line resistance does not
exceed 30ohm and is not connected to any foreign devices. The correct voltage on the line at rest should be within
the range of 9-10V, and during the call 4.5-5.5V
ELECTRIC STRIKE is controlled from the PC-4000 panel board. The electric main strike is connected to the LOCK1
and GND output, and the additional electric strike to the LOCK2 and GND output. The maximum load capacity of
the LOCK1 output is 12V 750mA, and the LOCK2 output are 12V 250mA. The LOCK1 output can be directly
controlled by an electric strike, a reverse action version / jumper. The LOCK2 output is recommended to control the
relay module.
BUTTON FOR EXITING A BUILDING, connect the PC-4000 panel to the WZ and GND terminals. This button can
be any NO button.
SLAVE PANELS to your CC-4000 master control panel under the SLAVE terminal in accordance with the pin
markings. The slave panel camera module is connected to the SLAVE terminal on the CC-4000 board.
