~3~
3.5.5. Deleting of all subscribers' all electronic keys ......................................................................................................................................... 13
3.5.6. Deleting of all non-recorded electronic keys ........................................................................................................................................... 13
4. System connection ................................................................................................................................................. 13
5. Using the intercom ................................................................................................................................................. 14
5.1. Connection to the property ..................................................................................................................................... 14
5.2. Using opening codes .............................................................................................................................................. 15
5.3. Quick entry to the staircase function ....................................................................................................................... 15
5.4. Office mode ........................................................................................................................................................... 15
6. Connection diagrams ........................................................................................................................................... 16
6.1. Basic video ............................................................................................................................................................ 16
6.2. Basic audio ............................................................................................................................................................ 18
6.3. Multi-input system .................................................................................................................................................. 20
7. Installer functions ................................................................................................................................................. 22
7.1. Recovery of the installer passcode ......................................................................................................................... 22
7.2. Service key fob ...................................................................................................................................................... 22
7.3. Installation mode .................................................................................................................................................... 22
7.4. Searching for short circuits ..................................................................................................................................... 23
8. Diagnostics ........................................................................................................................................................... 24
8.1. Types of addressing ............................................................................................................................................... 24
8.2. Error codes ............................................................................................................................................................ 24
8.3. RS-485 monitor...................................................................................................................................................... 25
1. SYSTEM FEATURES
CC4000
It is an intercom system with digital dialing. Main components:
• PC-4000 panel
It has a housing made of acid-resistant steel, metal backlit mechanical keyboard and an eight-digit alphanumeric
display with heating. The backlight of the display has a day/night brightness adjustment. Integrated energy-saving
UNIQUE 125kHz proximity key. Automatic light sensor. Wide-angle camera module with IR illuminator and angle
adjustment.
Independent combination lock. Individual intro. USB interface for editing and archiving panel parameters.
• CC-4000 control electronics
With the option of installation inside the PC-4000 panel, as well as in the outer plastic housing. It manages
audio/video signals. Its internal memory stores all subscriber settings with their entry codes, proximity keys and
non-recorded shared keys (2048 subscriber keys and 1024 unrecorded keys) 1024 subscriber entry codes (four per
one number) + one shared code. It is characterized by very low power consumption in idle mode - about 40mA. USB
interface for editing and archiving control panel parameters.
