SERVOPCBPARTLIST
©CyrusAudioLtdJun2014 22 CDtServiceManualIssue1
RP401 SMDCAY16 100R TF1/16W5%

RP402 SMDCAY16 100R TF1/16W5%

RP403 SMDCAY16 100R TF1/16W5%

CAPACITORS
C401 SMD0603 22n CP25V10%

C402 SMD0603 22n CP25V10%

C403 SMD0603 10n CP25V10%

C404 CAPSMD4.0 22uF EL16V20%

C405 SMD0603 22n CP25V10%

C406 SMD0603 100n CP25V10%

C407 SMD0603 100n CP25V10%

C408 SMD0603 100n CP25V10%

C409 SMD0603 1n5 CP50V5%

C410 CAPSMD4.0 22uF EL16V20%

C411 SMD0603 22n CP25V10%

C412 SMD0603 22n CP25V10%

C413 CAPSMD4.0 22uF EL16V20%

C414 SMD0603 47n CP25V10%

C415 CAPSMD4.0 22uF EL16V20%

C416 SMD0603 100n CP25V10%

C417 SMD0603 100n CP25V10%

C418 SMD0603 22n CP25V10%

C419 SMD0603 100n CP25V10%

C420 SMD0603 22n CP25V10%

C421 SMD0603 22n CP25V10%

C422 CAPSMD4.0 22uF EL16V20%

C423 SMD0603 33pF CP50V5%

C425 SMD0603 100n CP25V10%

C426 SMD0603 100n CP25V10%

C427 CAPSMD6.3 100uF EL10V20%

C428 SMD0603 100n CP25V10%

C430 SMD0603 22n CP25V10%

C431 CAPSMD6.3 100uF EL10V20%

C432 SMD0603 1n5 CP50V5%

C434 SMD0603 1n5 CP50V5%

C435 SMD0603 1n5 CP50V5%

C437 SMD0603 1n5 CP50V5%

C438 SMD0603 1n5 CP50V5%

C441 SMD0603 Notfitted

C446 SMD0603 33pF CP50V5%

C447 SMD0603 100n CP25V10%

C448 SMD0603 100n CP25V10%


Key:
CP=ceramicplate.EL=electrolytic.PE=polyester.PP=polypropylene.BP=bi‐polar.
CAPSMD6.3referstosurfacemountdevicewith6.3mmpitchpads
SMD‐0805referstosurfacemountdevicesizecode0805
DIODES
D401 LED_5MM TSAL6200 ThroughHoleIRLED.

D402 LED_5MM TSAL6200 ThroughHoleIRLED.

D403 SOD‐123 1N4148W‐V‐GS08 smallsignaldiode

D404 SOD‐123 1N4148W‐V‐GS08 smallsignaldiode

D405 SOD‐123 1N4148W‐V‐GS08 smallsignaldiode

