SERVOPCBPARTLIST
©CyrusAudioLtdJun2014 23 CDtServiceManualIssue1
D406 SOD‐123 1N4148W‐V‐GS08 smallsignaldiode

TRANSISTORS
T401 SOT23 BC817‐25 SignalTransistor

T402 SOT23 PDTB113ZT Digitaltransistor

T403 SC‐74‐2 IMX17T110 DualNPNtransistor

INTEGRATEDCIRCUITS
IC401 LQFP80 SAA7826HL/M1AS/S5 PhonICCDdecoder

IC402 HSOP28 BA5984FP‐E2 5channelmotordriver

VOLTAGEREGULATORS
VR401 SOT223 LM1117MPX‐3.3 SMD+3v3regulator.

FILTERS,INDUCTORS&CRYSTALS
X401 GSX‐751 8.4672MHz MP04546

CONNECTORS&SOCKETS
CON401
CONZIF24‐
SM_0.5MM
046240024006800+ 24wayLIFconnector

CON402 CON4‐JST‐SMS
S4B‐PH‐SM4‐
TB(LF)(SN)
4waySILheader

CON403 CON3‐JST‐SMS
S3B‐PH‐SM4‐
TB(LF)(SN)
3‐waySILheader

CON404 CON6‐JST‐SMS
S6B‐PH‐SM4‐
TB(LF)(SN)
6‐waySILheader

CON405 CONZIF25 52271‐2579 25wayZIFconnector

SK401 SKT_SMB Notfitted

TP414 PAD6.0x6.2 S1951‐46R Springterminal

TP415 PAD6.0x6.2 S1951‐46R Springterminal

