INSTALLATION Cyrus Power Amplifier
English
10
Chain Output.
The Chain outputs
4
allow more than one Cyrus Power
to be connected to a Pre-Amplifier.
Note:
The chain output is operational whether RCA
phono or Balanced XLR input connection is made to the
Cyrus Power.
Bi-Amplification
The Chain facility can be used with two or more Cyrus
Powers for Bi/Tri-amping by connecting the Chain output
of the first Cyrus Power to the RCA inputs of the next
Cyrus Power. Such a bi-amplified system provides the
sonic benefits of totally separate power amplification for
the bass and treble units of the loudspeakers.
Multi-speaker systems
In special cases it may be desirable to run more than one
set of loudspeakers in a room. The chain output enables
multiple Cyrus Powers to be used in this application also.
Chain output connection from a
Cyrus Power
When adding a second or third Cyrus Power to a system,
connect a quality RCA phono interconnect from the Chain
output RCA jacks
4
to the input
5
of the new Cyrus
Power. For Mbloc chain installations, connect the left
chain output of each Mbloc power amplifier to the
MBLOC inputs of the new amplifiers.
Rear view of a typical Cyrus Pre &
Cyrus Power bi-amplified stereo
system using the chain output to
drive a second power amplifier. In
this configuration, one amplifier will
drive the loudspeakers' woofers, the
other will drive the tweeters.
