95D-Link DIR-868L User Manual
Section 3 - Conguration
IPv6 Firewall
The DIR-868L’s IPv6 Firewall feature allows you to congure which kind of IPv6 trac is allowed to pass through the device.
The DIR-868L’s IPv6 Firewall functions in a similar way to the IP Filters feature.
Check the box to enable the IPv6 rewall simple security.
Select an action from the drop-down menu.
Enter a name to identify the IPv6 rewall rule.
Use the drop-down menu to select the time schedule that the IPv6
Firewall Rule will be enabled on. The schedule may be set to Always,
which will allow the particular service to always be enabled. You can
create your own times in the Tools > Schedules section.
Use the Interface drop-down menu to specify the interface that
connects to the source IPv6 addresses of the rewall rule.
Enter the source IPv6 address range in the adjacent IP Address
Range eld.
Use the Interface drop-down menu to specify the interface that connects to the destination IP addresses of the rewall rule.
Select the protocol of the rewall port (All, TCP, UDP, or ICMP).
Enter the rst port of the range that will be used for the rewall rule in the rst box and enter the last port in the eld in the second
box.
Enable IPv6
Simple Security:
Congure IPv6
Filtering below:
Name:
Schedule:
Source:
IP Address Range:
Dest:
Protocol:
Port Range:
