4D-Link DIR-868L User Manual
Section 1 - Product Overview
3
1
4
5
6
2
Hardware Overview
Connections
1 USB Port Connect a USB ash drive to share content throughout your network.
2 WPS Button Press to start the WPS process. The Power LED will blink during this process.
3 LAN Ports (1-4) Connect 10/100/1000 Ethernet devices such as computers, switches, storage (NAS) devices, and game consoles.
4 Internet Port Using an Ethernet cable, connect your broadband modem to this port.
5 Power Button Press the power button to power on and o.
6 Power Receptor Receptor for the supplied power adapter.
7 Reset Button Press and hold the reset button with a paper clip for ten seconds to reset the router to the factory default settings.
7
