DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
Parameter Description
MAC
A MAC address assigned to the interface. This parameter is
mandatory if your ISP uses MAC address binding. In the field, enter
the MAC address registered by your ISP upon concluding the
agreement.
You can click the Clone MAC button to set the MAC address of
the network interface card (of the computer that is being used to
configure the access point at the moment) as the MAC address of
the WAN interface.
Also you can set the address of a device connected to the access
point's LAN at the moment. To do this, select the relevant value
from the drop-down list located to the right of the field (the field
will be filled in automatically).
Figure 102. The page for creating a new connection. The IP and Miscellaneous sections.
Parameter Description
IP
Obtain DNS server
addresses
automatically
Select the checkbox to configure automatic assignment of DNS
server addresses. If the checkbox is selected, the Primary DNS
server and Secondary DNS server fields are not displayed.
Primary DNS server/
Secondary DNS server
Enter addresses of the primary and secondary DNS servers in the
relevant fields.
Vendor ID
The identifier of your ISP. Optional.
Miscellaneous
Enable RIP
Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
