DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Access Point Mode)
Net
In this menu you can configure basic parameters of the local area network of the access point.
LAN
To configure the access point's local interface, proceed to the Net / LAN page.
Figure 33. Basic settings of the local interface.
If needed, edit the basic settings of the local interface.
Parameter Description
IP Address
The IP address of the access point in the local subnet. By default, the
following value is specified: 192.168.0.50.
Netmask
The mask of the local subnet. By default, the following value is
specified: 255.255.255.0.
When needed settings are configured, click the Save button.
In the Static DHCP section, you can specify MAC address and IP address pairs (set a fixed IP
address in the local area network for a device with a certain MAC address). The access point
assigns IP addresses in accordance with the specified pairs only when the DHCP server is enabled
(in the DHCP server section, in the Mode drop-down list, the Enable value is selected).
Figure 34. The section for creating MAC-IP pairs.
To create a MAC-IP pair, click the Add button. Enter the MAC address of the device from the LAN
in the MAC address field and an IP address which will be assigned to this device in the IP
address field. In the Host name field, specify a network name of the device for easier
identification (optional).
Also you can create a MAC-IP pair for a device connected to the access point's LAN at the moment.
To do this, select the relevant value from the Known IP/MAC addresses drop-down list (the IP
address and MAC address fields will be filled in automatically).
When all needed MAC-IP pairs are specified, click the Save button.
Existing MAC-IP pairs are displayed in the table of the Static DHCP section. To remove a pair,
select the relevant line in the table and click the Remove button. Then click the Save button.
Page 39 of 175
