DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
Parameter Description
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Figure 105. The page for creating a new connection. The VPN and Miscellaneous sections.
Parameter Description
VPN
Connect automatically
Select the checkbox to enable auto-start of the connection upon the
boot-up of the access point.
Username A username (login) to access the Internet.
Without authorization
Select the checkbox if you don't need to enter a username and
password to access the Internet.
Password
A password to access the Internet.
Password confirmation
The confirmation of the entered password (to avoid mistypes).
Page 115 of 175
