DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
The following fields are available on the page:
Parameter Description
WDS Mode
The WDS function mode.
Disable: The function is disabled.
Bridge mode: Access points communicate to each other only,
wireless devices cannot connect to them.
Repeater mode: Access points communicate to each other,
wireless clients can connect to the WLAN created by interconnected
access points.
WDS Phy Mode
A physical mode of data transfer between access points
interconnected via the WDS function.
CCK: 802.11b devices only.
OFDM: 802.11g devices only.
HTMIX: 802.11g and 802.11n devices.
GREENFIELD: 802.11n devices only.
WDS Encryption
A type of encryption for data transfer between access points
interconnected via the WDS function.
NONE: No encryption.
WEP.
TKIP.
AES.
Encryption Key
A key for the specified type of encryption. If the NONE value is
selected from the WDS Encryption drop-down list, the field is not
displayed.
WDS MAC (1-4)
The MAC addresses of devices connected to the access point via the
WDS function.
!
The WDS function parameters specified on the page must be the same for all
interconnected devices. In addition, it is required to set the same channel (on the Wi-Fi /
Basic settings page).
When you have configured the parameters, click the Change button.
