DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
In the Username field, enter your login, and in the Password and Password confirmation
fields – the password provided by your ISP.
If authorization is not required, select the Without authorization checkbox.
If needed, specify additional settings for your PPPoE WAN connection.
Figure 65. Configuring PPPoE WAN connection.
Parameter Description
Service name
The name of the PPPoE authentication server.
Authentication
algorithm
Select a required authentication method from the drop-down list or
leave the AUTO value.
MTU
The maximum size of units transmitted by the interface.
Page 74 of 175
