DAP-1325 Quick Installation Guide
6. Search for available wireless networks.
7. In the opened Wireless Network Connection window, select the
wireless network DAP-1325 and click the Connect button.
8. In the opened window, enter the network key (see WPS PIN on the
barcode label on the back panel of the device) in the Network key and
Confirm network key fields and click the Connect button.
After that the Wireless Network Connection Status window appears.
Now you can connect to the web-based interface of DAP-1325 for configuring
all needed parameters. To gain access to an external network (to the Internet),
you also need to specify the default gateway and the addresses of DNS servers.
!
If you perform initial configuration of the extender via Wi-Fi
connection, note that immediately after changing the wireless default
settings of the extender you will need to reconfigure the wireless
connection using the newly specified settings.
10
