D-Link DAP-2682 User Manual

8D-Link DAP-2682 User Manual
Section 2 - Installation
Basic Installation
Hardware Setup
To power on the DAP-2682, you can use ONE of the following methods:
1. Plug one end of your Ethernet cable into the LAN port of the DAP-2682, and the other end into a port on a 802.3at PoE switch.
2. Purchase a DPE-301GI PoE injector separately if you need to connect the access point without a 802.3at PoE Switch.
Congure the access point
To set up and manage the DAP-2682, use one of the following methods:
1. Connect the access point and your computer to the same PoE switch. Manage the access point from the computer.
Enter dap2682.local in the address eld of your browser.
Log in to the Administration Web pages. The default login information is:
Username: admin
Password: admin
2. Connect the access point and your computer via DPE-301GI PoE injector. Manage the access point from the computer.
Enter dap2682.local in the address eld of your browser.
Log in to the Administration Web pages. The default login information is:
Username: admin
Password: admin
OR
Computer
802.3at PoE Switch
DAP-2682
Computer
PoE Injector
Power
Adapter

D-Link DAP-2682 Specifications

General

2.4 GHz	Yes
MIMO type	Multi User MIMO
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u
Virtual LAN features	Multiple VXLAN (MUX VLAN)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mean time between failures (MTBF)	341897 h
Maximum data transfer rate (5 GHz)	1700 Mbit/s
Maximum data transfer rate (2.4 GHz)	600 Mbit/s
Security algorithms	64-bit WEP, 128-bit WEP, WPA2
Number of SSID supported	16
Service Set Identifier (SSID) features	SSID broadcast
USB 2.0 ports quantity	-
Ethernet LAN (RJ-45) ports	2
Input current	2.5 A
AC input voltage	12 V
Power consumption (max)	15.5 W
Placement	Ceiling, Wall
Certification	FCC, CE, UL
Product color	White
LED indicators	Power, Status
Antenna type	Internal
Antenna gain level (max)	4.8 dBi
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Width	190 mm
Height	43.7 mm
Weight	551.6 g
