DGS-3100 Series Gigabit Stackable Managed Switch User Manual
Figure 0–12. VLAN Trunking Page
The VLAN Trunking Page contains the following fields:
Field Description
VLAN Trunking
Setting
Defines whether VLAN Trunking Settings are enabled on the device. The possible field
values are:
Enable — Enables VLAN Trunking Settings on the device.
Disable — Disables VLAN Trunking Settings on the device. This is the default value.
Unit
Defines the stacking member’s Unit ID for which VLAN Trunking parameters are displayed
Uplink Ports
Displays the Uplink ports which are included in the VLAN Trunking.
Ports
Displays the ports which are included in VLAN Trunking.
2. Enable VLAN Trunking.
3. Select a stacking unit in the Unit field.
4. Check the ports to be added to the VLAN Trunking. The port numbers are displayed in the Uplink Ports field.
5. Click
. The VLAN Trunking settings are saved, and the device is updated
79
