xStack
®
DGS-3200 Series Layer 2 Gigabit Ethernet Managed Switch
173
Ports
Ticking the All Ports check box will denote all ports on the Switch.
To view the settings of a previously correctly configured rule, click the corresponding Show Details button on the CPU Access
Rule List window to view the following window:
Figure 6 - 36. CPU Access Rule Detail Information window for IPv4
To establish the rule for a previously created CPU Access Profile:
To configure the Access Rules for IP, open the CPU Access Profile List window and click Add/View Rules for an IPv6 entry.
This will open the following window.
Figure 6 - 37. CPU Access Rule List window for IPv6
To remove a previously created rule, click the corresponding Delete Rules button. To add a new Access Rule, click the Add Rule
button:
Figure 6 - 38. Add Access Rule window for IPv6
