D-Link DIR-300A User Manual

DIR-300A Wireless N150 Router
User Manual
Installation and Connection
Connecting to PC
PC with Ethernet Adapter
1. Make sure that your PC is powered off.
2. Connect an Ethernet cable between any of LAN ports located on the back panel of the router
and the Ethernet port of your PC.
3. Connect the power cord to the power connector port on the back panel of the router, then
plug the power adapter into an electrical outlet or power strip.
4. Turn on the router by pressing the POWER button on its back panel.
5. Turn on your PC and wait until your operating system is completely loaded.
Obtaining IP Address Automatically in OS Windows XP
1. Click the Start button and proceed to the Control Panel > Network and Internet
Connections > Network Connections window.
2. In the Network Connections window, right-click the relevant Local Area Connection
icon and select the Properties line in the menu displayed.
Figure 3. The Network Connections window.
Page 17 of 181

D-Link DIR-300A Specifications

General

Frequency Band	2.4GHz
Wireless Speed	Up to 300 Mbps
Antennas	2
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
Wireless Standards	IEEE 802.11b/g/n
Ports	4 x 10/100 Mbps LAN, 1 x 10/100 Mbps WAN
Security	WPA/WPA2, WPS
Antenna Type	External, fixed
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 65°C
