DIR-300A Wireless N150 Router
User Manual
Configuring via Web-based Interface
Parameter Description
Static IP Address
For the PPPoE Dual Stack type only.
Fill in the field if you want to use a static IP address to access the
Internet.
Figure 69. The page for creating a new Pv6 PPPoE connection. The IPv6 section.
Parameter Description
IPv6
Get IPv6
Select a method for IPv6 address assignment from the drop-down
list or leave the Automatically value.
Figure 70. The page for creating a new Pv6 PPPoE connection. The IPv6 gateway section.
Parameter Description
IPv6 gateway
SLAAC
Select the checkbox to automatically assign the IPv6 gateway
address with help of SLAAC (Stateless Address Autoconfiguration).
Static IPv6 gateway
address
The static address of the IPv6 gateway. The field is available for
editing, if the SLAAC checkbox is not selected.
Page 85 of 181
