DIR-853 AC1300 MU-MIMO Wi-Fi Gigabit Router
with 3G/LTE Support and USB Port 3.0
User Manual
Overview
Port Description
WPS
A button to set up wireless connection (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The WPS LED should start
blinking.
WIFI
A button to enable/disable wireless network.
To disable the router's wireless network: with the device turned on,
press the button and release. The WLAN 2.4G and WLAN 5G LEDs
should turn off.
12V DC IN Power connector.
POWER A button to turn the router on/off.
The device is also equipped with four external non-detachable Wi-Fi antennas.
Page 17 of 228
