D-Link DIR-865L User Manual

5D-Link DIR-865L User Manual
Section 1 - Product Overview
3
1
4
5
6
2
Hardware Overview
Connections
1 USB Port Connect a USB ash drive to share content throughout your network.
2 LAN Ports (1-4) Connect 10/100/1000 Ethernet devices such as computers, switches, storage (NAS) devices and game consoles.
3 Internet Port Using an Ethernet cable, connect your broadband modem to this port.
4 Reset Button Press and hold for 6 seconds to reset the device back to the default factory settings.
5 Power Button Press the power button to power on and o.
6 Power Receptor Receptor for the supplied power adapter.

D-Link DIR-865L Specifications

Device Interfaces

wireless LAN	802.11 a/b/g/n/ac
Gigabit LAN ports	Four 10/100/1000
Gigabit WAN port	10/100/1000
USB port	USB 3.0

Power

input voltage	100 to 240 V AC
input frequency	50/60 Hz
output voltage	12 V DC
output current	2.5 A
USB port power	5 V / 0.9 A

Operating Environment

operating temperature	32°F to 104°F (0°C to 40°C)
humidity	95% maximum (non-condensing)

Weight and Dimensions

length	102.3 mm (4.03 inches)
width	123.3 mm (4.85 inches)
height	217 mm (8.54 inches)
