Log Backup
Log Backup to HTTP
This window is used to initiate a system log backup to a local PC using HTTP.
To view the following window, click Tools > Log Backup > Log Backup to HTTP, as shown below:
Click the Backup button to initiate the system log backup.
Log Backup to TFTP
This window is used to initiate a system log backup to a TFTP server.
To view the following window, click Tools > Log Backup > Log Backup to TFTP, as shown below:
TThe fields that can be configured are described below:
Parameter Description
TFTP Server IP
Enter the TFTP server’s IPv4 address here.
Destination File
Enter the destination filename and path where the log file should
be stored on the TFTP server. This field can be up to 64
characters long.
Click the Backup button to initiate the system log backup.
Figure 3-11 Log Backup to HTTP window
Figure 3-12 Log Backup to TFTP window
