D-Link Dis-200G Series

DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch
92
Port Security Address Entries
This window is used to view, clear and configure the port security address entries.
To view the following window, click Security > Port Security > Port Security Address Entries, as
shown below:
The fields that can be configured are described below:
Parameter Description
Port
Select the port used for the configuration here.
MAC Address
Enter the MAC address here.
Click the Clear by Port button to clear the information based on the port selected.
Click the Clear by MAC button to clear the information based on the MAC address entered.
Click the Clear All button to clear all the information in this table.
Figure 8-3 Port Security Address Entries window
