Configuring via Web-based Interface
WAN Remapping
On the Advanced / WAN Remapping page, you can configure the router to connect to a private
Ethernet line.
!
The Ethernet WAN function allows using any Ethernet port of the router to access the
Internet via Ethernet technology. When the function is enabled, the router is still able to
access the Internet via ADSL technology.
Figure 96. The Advanced / WAN Remapping page.
To use one of the router's LAN port as the WAN port, click the icon corresponding to this port and
click the APPLY button. Port configured as the WAN port is highlighted in teal.
If in the future you need to disconnect the LAN port from the private Ethernet line, click the icon
highlighted in teal and click the APPLY button.
Page 126 of 174

D-Link DSL-2740U Specifications

Data Transfer Rates

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite downstream	up to 1.5 Mbps
G.lite upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface connector	RJ-11
ADSL interface cable	24/26 AWG twisted pair
LAN interface connector	RJ-45
LAN interface standard	10/100BASE-T Ethernet
