D-Link DSL-2877AL User Manual

D-Link DSL-2877AL Dual Band Wireless AC750 VDSL/ADSL2+ Modem Router User Manual
Section 2- Basic Installation
Page 23
Getting Started
This section will show you how to set up and configure your new D-Link router using the Web-based configuration utility.
How to connect to the Web User Interface
Connect to the Router
To configure the WAN connection used by the router it is first necessary to communicate with the router through its management interface, which is HTML-based and can be
accessed using a web browser. The easiest way to make sure your computer has the correct IP settings is to configure it to use the DHCP server in the router.
To access the web user interface, open a web-browser such as Internet Explorer and
enter the IP address of the router (192.168.1.1) into the address bar and press the
Enter key on your keyboard.
Type “admin” in the User Name field and “admin” in the Password field, and click the
Login button to proceed. If you get a Page Cannot be Displayed error, please refer to
the Troubleshooting section for

D-Link DSL-2877AL Specifications

General

LAN Ports	4 x 10/100Mbps
USB Ports	1 x USB 2.0
Frequency Band	2.4 GHz
WAN Ports	1 x RJ-11 DSL port
Antenna Type	2 External Antennas
Security	WPA, WPA2
Weight	270 grams
